Technical Data Sheet
Kentmere Basin Unit 600 Two Drawer Standard
4406KM
Technical Drawings
All dimensions in mm. Please check dimensions prior to installation.
Technical Details
Furniture Type:
Basin Unit
Dimensions (WxDxH):
600 x 303 x 811mm
Carcass Material:
MFC 18mm
Carcass Edging:
PVC Edging
Carcass Service Area:
Open Back
Fascia Style:
MDF 19mm Shaker
Fascia Detail:
Shaker Frame
Handle Type:
Integrated Handle
Drawers:
2 drawers, Emuca Soft Close, 350mm runners
Fixation Method:
Adjustable Metal Wall Brackets, 80mm from top @ 535mm centres
Leg / Foot Type:
Leg Sockets, Legs Included
Compatible Basins:
37.3173, 37.3113, 37.3095, 37.3853, 37.9172, 37.9112, 37.9177, 37.9321, 37.9075, 37.9175, 37.3506, 37.3507, 37.9171, 37.9163, 37.9324, 37.3191, 37.3192, 37.3195, 37.3196, 37.3538, 37.3072, 37.3071, 37.307, 37.3608, 37.3601, 37.3602, 37.3603, 37.3604, 37.3607, 37.3605, 37.3606, 3080, 3540, 3687, 3688, 3686
Dimensional Tolerance:
Please note that all dimensions have a tolerance of +/- 2mm.
In The Box:
Kentmere Basin Unit 600 Two Drawer Standard
Instructions
Fitting kit
