Dartmoor Tall Wall Unit 500 Two Door Standard

1498DA

All dimensions in mm. Please check dimensions prior to installation.

Furniture Type:

Tall Wall Unit

Dimensions (WxDxH):

500 x 218 x 1222mm

Carcass Material:

MFC 18mm

Carcass Edging:

PVC Edging

Carcass Service Area:

Closed Back

Fascia Style:

MDF 18mm Shaker

Fascia Detail:

Slim Shaker Frame

Door Openings:

Door(s) Hinge Side:

Both

Hinges Detail:

Soft close

Hinge Bracket Cover Plates:

Yes

Handle Type:

Handle Not Included

Shelves:

4 removable - Glass 5mm

Removable Shelf Supports:

Clamps

Fixation Method:

Adjustable Metal Wall Brackets, 80mm from top @ 435mm centres

Door Open Unit Depth:

450mm

Dimensional Tolerance:

Please note that all dimensions have a tolerance of +/- 2mm.

Dartmoor Tall Wall Unit 500 Two Door Standard
Instructions
Fitting kit
